    Aten VS381B 3 Port Giriş 1 Port Çıkış 4K Dişi-Dişi 4K HDMI Görüntü Çoklayıcı

    Aten VS381B 3 Port Giriş 1 Port Çıkış 4K Dişi-Dişi 4K HDMI Görüntü Çoklayıcı Aten VS381B 3 Port Giriş 1 Port Çıkış 4K Dişi-Dişi 4K HDMI Görüntü Çoklayıcı Aten VS381B 3 Port Giriş 1 Port Çıkış 4K Dişi-Dişi 4K HDMI Görüntü Çoklayıcı
    Görsel 1
    Görsel 2
    Görsel 3
    PlatinPuan : 2.188.952
    Fiyat:
    2.765,00 TL
    Havale / EFT:
    2.695,88 TL
    359,45 TL'den başlayan taksit seçenekleri için tıklayın.

    Ürüne Oy Verin

    Aten VS381B 3 Port Giriş 1 Port Çıkış 4K Dişi-Dişi 4K HDMI Görüntü Çoklayıcı

    • Allows up to 3 HDMI input sources to be transmitted to 1 HDMI output display
    • Superior video quality – True 4K resolution of 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4) up to 5m; HDR supported
    • HDMI (3D, Deep Color, 4K, HDR10+, Dolby Vision, HLG)
    • HDCP 2.2 compliant
    • Auto switching mode for auto port selection
    • Switching between HDMI input sources via front panel pushbuttons and IR remote control
    • Supports IR extension
    • Supports 7.1 channel audio output
    • Clear LED indication of device status
    • Plug-and-play – no software installation required



    NoteUSB to DC cable as the main power source;
    In some circumstances power from HDMI maybe sufficient for the device; however, the power source from USB via USB to DC cable is recommended for device operation
    LEDs
    Input3 x HDMI-In (Green)
    Power1 x Power LED (Green)
    Pushbuttons
    Select1 x push button (input selection)
    Audio
    Input3 x HDMI Type A Female (Black)
    Output1 x HDMI Type A Female (Black)
    Video Input
    Interfaces3 x HDMI Type A Female (Black)
    Impedance100 ?
    Max. DistanceMax 5m @ Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)
    Video Output
    Interfaces1 x HDMI Type A Female (Black)
    Impedance100 ?
    Max. DistanceMax 5m @ Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)
    Video
    Max. Data Rate18 Gbps (6 Gbps Per Lane)
    Max. Pixel Clock600 MHz
    ComplianceHDMI 2.0 (3D, Deep Color, 4K, HDR10, Dolby Vision)
    HDCP 2.2
    Max. Resolution4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)
    Control
    IR1 x Mini Stereo Jack Female (Black) / Max distance@ 5m
    Connectors
    Power1 x DC Jack
    Power ConsumptionDC5V:1.46W:6BTU
    Environmental
    Operating Temperature0-40 °C
    Storage Temperature-20 - 60 °C
    Humidity0 - 80% RH, Non-Condensing
    Physical Properties
    HousingMetal
    Weight0.15 kg ( 0.33 lb )
    Dimensions (L x W x H)7.16 x 7.90 x 2.55 cm
    (2.82 x 3.11 x 1 in.)



    Diğer Özellikler
    Stok KoduATEN-VS381B
    MarkaATEN
    Stok DurumuVar
    4710469340383
